Schneider HMIDM6700WCCTO

HMIDM6700WCCTO · Umweltfreundlichkeit des Produkts Weitere Informationen

法国 施耐德 Schneider
基本信息

型号: HMIDM6700WCCTO

暂无参考面价,可询价获取报价

Umweltfreundlichkeit des Produkts Weitere Informationen
  • Umweltfreundlichkeit des Produkts Weitere Informationen
基本属性
净重:4.000 KG
毛重:6.000 KG
宽度:408 mm
高度:264 mm
Hauptmerkmale
Baureihe:
Harmony P6
Produkt- oder Komponententyp:
Touchscreen-Bildschirm
Zusatzmerkmale
Displaygröße:
15,6 Zoll
Seitenverhältnis:
16:9
Anzeigefarbe:
16 Millionen Farben
Pixelauflösung:
1366 x 768
Einschaltstrom:
30 A
Gerätemontage:
  • Panel mounting
  • Direkte Montage VESA
Abmessungen des Ausschnitts:
394 (+ 1/- 0) x 250 (+ 1/- 0) mm
Breite:
408 mm
Höhe:
264 mm
Produktgewicht:
4,0 kg
Montage
Produktzertifizierungen:
  • RCM
  • KC
  • ATEX
  • CE
  • UKCA
  • DNV (DC model without HDD/fan/ EtherCAT card/22" wide display with expansion slot)
  • ATEX Zone 22 Dust (DC model, front USB cover must be locked with screw)
  • ATEX Zone 2 (DC model, front USB cover must be locked with screw)
  • CULus Class 1 Division 2 (without DIO option)
  • IECEx zone 2 (DC model, front USB cover must be locked with screw)
  • IECEx zone 22 (DC model, front USB cover must be locked with screw)
Umgebungstemperatur bei Betrieb:
0…60 °C
Verschmutzungsgrad:
2
Betriebshöhe:
2.000 m
Stoßfestigkeit:
  • 147 m/s² entspricht IEC 61131-2
  • 147 m/s² 3 shocks in each direction X, Y and Z
Verpackungseinheiten
VPE 1 Art:
PCE
VPE 1 Menge:
1
VPE 1 Höhe:
15,0 cm
VPE 1 Breite:
28,0 cm
VPE 1 Länge:
39,0 cm
VPE 1 Gewicht:
3,5 kg
Vertragliche Gewährleistung
Gewährleistung:
18 Monate
