Bürkert 00443300

00443300 · Inline | 1.357,00l/h - 45.239l/h | -15,00 °C - 100,00 °C | PN 16 | Schweißende | Edelstahl

德国 宝德 Bürkert
基本信息

型号: 00443300

参考面价: €694.00 ≈ ¥5108.26 查看汇率详情 →

Inline | 1.357,00l/h - 45.239l/h | -15,00 °C - 100,00 °C | PN 16 | Schweißende | Edelstahl
基本属性
净重:1.210 KG
Sensor
Sensor Art:
Flügelrad
Flügelrad Werkstoff:
PVDF (Polyvinylidenfluorid)
Flügelrad Art:
magnetisch
Wirkungsweise
Fluidischer Leitungsanschluss Anzahl:
2
Medium & Kalibrierung
Dynamische Viskosität min.:
0 cP
Dynamische Viskosität max.:
300 cP
Messwerte
Messwert Volumendurchfluss min:
1.357
Messwert Volumendurchfluss max:
45.239
Einheit Messwert:
l/h
Prozess- / Leitungsanschluss
Leitungsanschluss 1 Typ:
Schweißende
Leitungsanschluss 1 Innendurchmesser (mm):
48,6 mm
Leitungsanschluss 1 Größe DN:
DN 50
Leitungsanschluss 1 Wandstärke (mm):
1,2 mm
Leitungsanschluss 1 Außendurchmesser (mm):
51 mm
Leitungsanschluss 1 Rohrnorm 1:
SMS 3008
Leitungsanschluss Werkstoff Kategorie:
Metalle
Leitungsanschluss Werkstoff:
Edelstahl
Werkstoffe
Druck & Temperatur
Dichtungsmaterial
Zulassungen
Geräteeigenschaften
