Bürkert 00428741

00428741 · Insertion 2 (Zoll) | 2.163,00l/h - 72.106l/h | -15,00 °C - 160,00 °C | PN 16 | Innengewinde | G2 | Edelstahl

德国 宝德 Bürkert
基本信息

型号: 00428741

参考面价: €507.00 ≈ ¥3731.82 查看汇率详情 →

Insertion 2 (Zoll) | 2.163,00l/h - 72.106l/h | -15,00 °C - 160,00 °C | PN 16 | Innengewinde | G2 | Edelstahl
基本属性
净重:1.800 KG
Wirkungsweise
Fluidischer Leitungsanschluss Anzahl:
2
Messwerte
Messwert Volumendurchfluss min:
2.163
Messwert Volumendurchfluss max:
72.106
Einheit Messwert:
l/h
Prozess- / Leitungsanschluss
Leitungsanschluss 1 Typ:
Innengewinde
Leitungsanschluss 1 Gewindebezeichnung:
2
Leitungsanschluss 1 Gewindeart:
G
Leitungsanschluss Werkstoff Kategorie:
Metalle
Leitungsanschluss Werkstoff:
Edelstahl
Werkstoffe
Armatur Werkstoff:
Edelstahl
Messrohr Werkstoff:
Edelstahl
Druck & Temperatur
Nenndruck (DIN EN 1333):
PN 16
Temperatur Medium min:
-15 °C
Temperatur Medium max:
160 °C
Dichtungsmaterial
Geräteeigenschaften
