Baumer VCXG-65C.R 11175750 原厂跨境采购

Baumer VCXG-65C.R 11175750 原厂跨境采购

VCXG-65C.R 11175750Industriekameras/CX-Serie

德国  Baumer

VCXG-65C.R 11175750

Baumer VCXG-65C.R 11175750 原厂跨境采购
VCXG-65C.R 11175750基本信息

型号: VCXG-65C.R

订货号: 11175750

Industriekameras / CX-Serie
  • 3072×2048像素
  • Sony IMX178
  • 1/1.8″ CMOS
  • 每秒19帧
  • Gigabit Ethernet
VCXG-65C.R 11175750基本属性
VCXG-65C.R 11175750Sensor Daten
Sensor:
Sony IMX178
Mono/Farbe:
Farbe
Sensor Typ:
1/1.8″ CMOS
Shutter Typ:
  • Rolling shutter
  • Global reset shutter
Auflösung:
3072 × 2048 px
Pixelgrösse:
2.4 × 2.4 µm
VCXG-65C.R 11175750Datenqualität (EMVA 1288 typical)
Dark Noise:
2,9 e-
Saturation Capacity:
14036 e-
Dynamikbereich:
71,8 dB
Signal-Rausch-Verhältnis:
41,5 dB
Quanteneffizienz:
  • 58,4 % @ 465 nm
  • 62,8 % @ 536 nm
  • 47,2 % @ 631 nm
VCXG-65C.R 11175750Bildaufnahmeformate
Bildformate, Bildrate Schnittstelle max.:
  • Full Frame, 3072 × 2048 px, max. 19 fps
  • Binning 2×2, 1536 × 1024 px, max. 29 fps
  • Binning 2×1, 1536 × 2048 px, max. 19 fps
  • Binning 1×2, 3072 × 1024 px, max. 29 fps
Bildformate, Bildrate Bildaufnahme max. (Burst Mode):
Full Frame, 3072 × 2048 px, max. 29 fps
Pixelformate:
  • BayerRG8
  • BayerRG10
  • BayerRG12
  • BayerRG12 Packed
  • Mono8
  • Mono10
  • Mono12
  • Mono12 Packed
  • RGB8
  • BGR8
VCXG-65C.R 11175750Bildmanipulation
Farbmodelle:
  • Mono
  • Raw Bayer
  • RGB
  • BGR
VCXG-65C.R 11175750Kamerafunktionen
Basisfunktionen:
  • Exposure
  • Gain / Color Gain
  • Trigger / Exposure Active (Flash)
  • Binning 2x2
  • Partial Scan
  • Offset
  • Free Running Mode (Live Bild)
Auto-Funktionen:
  • Exposure Auto
  • Gain Auto
  • White Balance Auto
  • Color Transformation Auto
Bildvorverarbeitung:
  • Color Processing (RGB, BGR, Mono)
  • Color Enhancement (mit ColorTransformationMatrix)
  • LUT / Gamma
Bildaufnahme / Schnittstelle:
  • Burst Mode
  • Adjustable Framerate
  • Device Link Throughput Limit
  • Interner Bildspeicher
Prozesssynchronisation:
  • Events
  • Timer
  • Trigger Delay
  • Debouncer
  • Counter
  • Trigger via Action CMD (GigE)
  • Additional Output Modes (e.g. Trigger Ready)
  • Chunk data inside transferred image
  • Encoder support via Counter End trigger source
Weitere Funktionen:
  • User Set
  • Integrated temperature sensor
  • Readable additional information (e.g. sensor information)
  • Save Custom Data
VCXG-65C.R 11175750Schnittstellen
VCXG-65C.R 11175750Mechanische Daten
VCXG-65C.R 11175750Elektrische Daten
VCXG-65C.R 11175750Umgebungsbedingungen
VCXG-65C.R 11175750Konformität
VCXG-65C.R
VCXG-65C.R 11175750 - Baumer产品主图

基本信息

型号: VCXG-65C.R

订货号: 11175750

Industriekameras / CX-Serie
  • ·3072×2048像素
  • ·Sony IMX178
  • ·1/1.8″ CMOS
  • ·每秒19帧
  • ·Gigabit Ethernet
Sensor Daten
Sensor:
Sony IMX178
Mono/Farbe:
Farbe
Sensor Typ:
1/1.8″ CMOS
Shutter Typ:
  • Rolling shutter
  • Global reset shutter
Auflösung:
3072 × 2048 px
Pixelgrösse:
2.4 × 2.4 µm
Datenqualität (EMVA 1288 typical)
Dark Noise:
2,9 e-
Saturation Capacity:
14036 e-
Dynamikbereich:
71,8 dB
Signal-Rausch-Verhältnis:
41,5 dB
Quanteneffizienz:
  • 58,4 % @ 465 nm
  • 62,8 % @ 536 nm
  • 47,2 % @ 631 nm
Bildaufnahmeformate
Bildformate, Bildrate Schnittstelle max.:
  • Full Frame, 3072 × 2048 px, max. 19 fps
  • Binning 2×2, 1536 × 1024 px, max. 29 fps
  • Binning 2×1, 1536 × 2048 px, max. 19 fps
  • Binning 1×2, 3072 × 1024 px, max. 29 fps
Bildformate, Bildrate Bildaufnahme max. (Burst Mode):
Full Frame, 3072 × 2048 px, max. 29 fps
Pixelformate:
  • BayerRG8
  • BayerRG10
  • BayerRG12
  • BayerRG12 Packed
  • Mono8
  • Mono10
  • Mono12
  • Mono12 Packed
  • RGB8
  • BGR8
Bildmanipulation
Farbmodelle:
  • Mono
  • Raw Bayer
  • RGB
  • BGR
Kamerafunktionen
Basisfunktionen:
  • Exposure
  • Gain / Color Gain
  • Trigger / Exposure Active (Flash)
  • Binning 2x2
  • Partial Scan
  • Offset
  • Free Running Mode (Live Bild)
Auto-Funktionen:
  • Exposure Auto
  • Gain Auto
  • White Balance Auto
  • Color Transformation Auto
Bildvorverarbeitung:
  • Color Processing (RGB, BGR, Mono)
  • Color Enhancement (mit ColorTransformationMatrix)
  • LUT / Gamma
Bildaufnahme / Schnittstelle:
  • Burst Mode
  • Adjustable Framerate
  • Device Link Throughput Limit
  • Interner Bildspeicher
Prozesssynchronisation:
  • Events
  • Timer
  • Trigger Delay
  • Debouncer
  • Counter
  • Trigger via Action CMD (GigE)
  • Additional Output Modes (e.g. Trigger Ready)
  • Chunk data inside transferred image
  • Encoder support via Counter End trigger source
Weitere Funktionen:
  • User Set
  • Integrated temperature sensor
  • Readable additional information (e.g. sensor information)
  • Save Custom Data
Schnittstellen
Mechanische Daten
Elektrische Daten
Umgebungsbedingungen
Konformität
